Baromax Underwater Connector

Baromax Connector Male (3-pin)

$50.00

SKU BM-A-3-M Categories ,

The Baromax Connector Male 3-pin is a wet-mate underwater connector with power capabilities up to 15A per contact.  The Baromax connector is rated for continous submersion up to 10,000 psi when potted with a Baromax backshell.

Please Note: Epoxy NOT Included

> Data Sheet

Quantity

Shop our Popular Product Kits

Never compromise, get more for less

Features



Download Data Sheet

Specifications:

Poles: 3
Mated Pressure: 10,000 psi (700bar)
Voltage rating: 400V DC
Contact current rating: 15A per contact (max 45A per connector)
Insulation Resistance: > 200 MΩ @ 300VDC between adjacent terminals
Initial Contact Resistance: < 2mΩ after 30 mate cycles
Final Contact Resistance: < 10mΩ after 500 mate cycles
Durability: 500 mating cycles
Operating Temperature (water): -4 to 60°C
Operating Temperature (air): -40 to 60°C
Connector: Neoprene
Contacts: Gold plated brass

Harmonized Code: 8536.69.4020

In Stock

Reduce lead time

Flexible

8-pin, 3-pin & more soon

Gigabit Ethernet Ready

Minimize untwisted cable length

Powerful

360° contacts

Rugged

10,000 psi pressure rating

Stay Connected

Locking ring mates & unmates

the suburban marine difference

Benefits

COMMERCIAL ROV

COMMERCIAL ROV

The Baromax line of underwater connectors are designed to eliminate lead time and increase up time. Equipment can be standardized and customized at the point of need.

EDUCATION

EDUCATION

Baromax can be configured rapidly at the point-of-need enabling support for multiple payloads and missions for the next generation of ocean innovators.

IMAGING

IMAGING

The Baromax allows more interface flexibility by supporting high speed ethernet signals and low speed auxiliary signals for modern underwater camera systems.

EXPLORATION

EXPLORATION

The Baromax series is a scalable tool that enables rapid and agile ocean innovation. Connectors can be changed between low/high speed, and power with one connector series.

direct support

Our team is always working to improve your experience. Take a look at these quick start guides. Get in touch with us if you have more questions!

How It Works

User Guides & Tutorials

Why baromax epoxy?

The Baromax Epoxy is an important accessory you do not want to forget. One bottle can complete up to 15 assemblies and is rated for harsh underwater environments with superior chemical resistance for moisture in continuous full submersion.

Shop Baromax epoxy

Shop Baromax epoxy kit
